Nominal attenuation: 300KHz~825MHz 5dB, 2.475GHz~4.125GHz 12dB~20dB
Features
Colour sampling: 4:4:4
Shield material: Aluminium
Contact material: Phosphor bronze
Connector housing material: Acrylonitrile butadiene styrene (ABS)
Bending radius (min): 10 cm
HDMI version: 2.0
Supported graphics resolutions: 4096 x 2160
Dolby technologies: Dolby TrueHD, DTS-HD Master Audio
Magnetically shielded: Yes
Cable material: Copper
Connector 2: HDMI Type A (Standard)
Supported video modes: 2160p
Connector 2 gender: Male
AWG wire size: 28
Cable length: 15 m
Product colour: Black
Connector 2 form factor: Straight
Connector material: Gold
Connector contacts plating: Gold
Cable jacket material: Polyvinyl chloride (PVC)
Data transfer rate: 18 Gbit/s
Connector 1 form factor: Straight
Connector 1: HDMI Type A (Standard)
Connector 1 gender: Male
Cable type: Round cable
Operational conditions
Storage temperature (T-T): -10 - 60 °C
Operating temperature (T-T): -20 - 80 °C
Weight & dimensions
Connector 1 dimensions (WxDxH): 21.68 x 43 x 13.22 mm
Connector 2 dimensions (WxDxH): 21.68 x 43 x 13.22 mm
Cable diameter: 8.6 mm
Packaging data
Package type: Polybag
Quantity per pack: 1 pc(s)
Certification: CE, UKCA, FCC, RoHS, REACH, UL
Certificates
Compliance certificates: RoHS
Logistics data
Harmonized System (HS) code: 84733080
Master (outer) case GTIN (EAN/UPC): 4002888410724
Safety warning
Warnings: Store the cable away from heat sources., Avoid bending the cable sharply to avoid damaging the internal wires., Avoid contact of the cable with water or moisture.
