Features Cable length: 1 m Supported graphics resolutions: 4096 x 2160 HDMI version: 2.0 Conductor material: Tinned copper Jacket material: Polyvinyl chloride (PVC) Connector 1 gender: Male Connector 2 form factor: Straight High Dynamic Range (HDR) supported: Yes AWG wire size: 30 Maximum resolution: 4096 x 2160 pixels Data transfer rate: 21.6 Gbit/s DisplayPort version: 1.2 Supported video modes: 2160p Product colour: Black Connector 2: DisplayPort Connector contacts plating: Nickel Connector 1: HDMI + USB Type-A Connector 2 gender: Male Connector 1 form factor: Straight Bandwidth: 60 MHz Cable type: Round cable Connector housing material: Acrylonitrile butadiene styrene (ABS) Bend radius (min): 3.6 cm Colour sampling: 4:2:2, 4:4:4
Operational conditions Storage temperature (T-T): -40 - 80 °C Operating temperature (T-T): -20 - 40 °C
Weight & dimensions Cable diameter: 6 mm Connector 1 dimensions (WxDxH): 50 x 20.9 x 12.7 mm Connector 2 dimensions (WxDxH): 35 x 15.5 x 7.8 mm Connector 3 dimensions (WxDxH): 38.9 x 19.7 x 12 mm
