Certification: CE, UKCA, FCC, RoHS, REACH & California Proposition 65
Design
LED indicators: Status
Product colour: Black
Hot keys: Yes
Rack mounting: No
Push button: Yes
Housing material: Metal
Power
Input voltage: 12 V
Power source: DC
Output current: 1 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 609 g
Width: 220 mm
Depth: 100 mm
Height: 30 mm
Performance
HDCP: Yes
HD type: 4K Ultra HD
Maximum resolution: 4096 x 2160 pixels
HDCP version: 2.3
Video bandwidth: 60 Hz
Packaging data
Package weight: 1.61 kg
Package type: Box
Package width: 300 mm
Package height: 115 mm
Package depth: 185 mm
Packaging content
Remote control included: Yes
Cables included: USB Type-A to Micro USB-B, DC, HDMI
Manual: Yes
Rack mount kit: Yes
Quick installation guide: Yes
Display
Built-in display: No
Ports & interfaces
USB connector type: USB Type-B, USB Type-A
DC-in jack: Yes
Number of computers controlled: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 2
Console ports: USB A, HDMI, 3.5mm headphone
Headphone outputs: 2
HDMI version: 2.0
Keyboard port type: USB
Mouse port type: USB
Video port type: HDMI
HDMI ports quantity: 4
Console USB ports quantity: 4
Audio connections: Yes
Other features
Warranty period: 2 year(s)
