Technical details
Connector 2: HDMI Type A
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, REACH
Connector 1: 2 x HDMI Type A
Warranty period: 2 year(s)
Certification: CE, FCC, RoHS, REACH & California Proposition 65
Features
Product colour: Black
HD type: 8K Ultra HD
Maximum refresh rate: 60 Hz
HDCP: Yes
Easy to install: Yes
Maximum resolution: 7680 x 4320 pixels
Colour depth: 8 bit
Housing material: Metal
Data transfer rate: 48 Gbit/s
HDCP version: 2.3
LED indicators: Yes
Power
Input current: 2 A
AC input voltage: 5 V
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 20 - 90%
Weight & dimensions
Weight: 325 g
Depth: 17 mm
Height: 68 mm
Width: 145 mm
Packaging data
Package depth: 70 mm
Package type: Box
Package weight: 458 g
Package height: 115 mm
Package width: 200 mm
Quantity per pack: 1 pc(s)
Packaging content
AC adapter included: Yes
Cables included: Power
Manual: Yes
Included power plug types: AU, EU, UK
Ports & interfaces
HDMI version: 2.1
Digital audio optical out: 1
Video ports quantity: 2
Headphone out: Yes
DC-in jack: Yes
Video out: 2x HDMI
Video port type: HDMI
Headphone connectivity: 3.5 mm
