Features Connector 2 form factor: Straight Connector contacts plating: Gold Connector 2: HDMI Type A (Standard) Maximum refresh rate: 120 Hz High Dynamic Range (HDR) technology: Dolby Vision, HDR 10+ HDMI version: 2.1 Connector 1: HDMI Type A (Standard) Connector 1 gender: Male Cable jacket material: Thermoplastic elastomer (TPE) Data transfer rate: 48 Gbit/s Connector 2 gender: Male AWG wire size: 32 High Dynamic Range (HDR) supported: Yes Magnetically shielded: Yes Connector 1 form factor: Straight Bending radius (min): 2 cm Supported graphics resolutions: 7680 x 4320, 3860 x 2160 Cable length: 100 m Product colour: Black Shield material: Aluminium Tensile strength: 100 N Colour sampling: 4:4:4, 4:2:0
Operational conditions Operating temperature (T-T): -10 - 60 °C Storage temperature (T-T): -20 - 70 °C
Weight & dimensions Cable diameter: 6 mm Connector 1 dimensions (WxDxH): 38 x 8.3 x 18.3 mm
Packaging data Quantity per pack: 1 pc(s) Certification: California Proposition 65
Certificates Compliance certificates: Federal Communications Commission (FCC), UKCA, REACH, RoHS, CE
