Technical details
Connector 2: HDMI Type A
Connector 1: 4 x HDMI Type A
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC), REACH
Warranty period: 2 year(s)
Certification: CE, FCC, RoHS, REACH & California Proposition 65
Features
LED indicators: Yes
HDCP: Yes
Product colour: Black
Maximum resolution: 7680 x 4320 pixels
HD type: 8K Ultra HD
Housing material: Metal
Maximum refresh rate: 60 Hz
Easy to install: Yes
Data transfer rate: 48 Gbit/s
HDCP version: 2.3
Colour depth: 8 bit
Power
AC input voltage: 5 V
Input current: 2 A
Operational conditions
Storage relative humidity (H-H): 20 - 90%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 176 mm
Weight: 375 g
Height: 68 mm
Depth: 17 mm
Packaging data
Package weight: 510 g
Package width: 240 mm
Package type: Box
Package height: 130 mm
Quantity per pack: 1 pc(s)
Package depth: 70 mm
Packaging content
Cables included: Power
Manual: Yes
AC adapter included: Yes
Included power plug types: AU, EU, UK
Ports & interfaces
Digital audio optical out: 1
HDMI version: 2.1
DC-in jack: Yes
Headphone out: Yes
Video out: 4x HDMI
Headphone connectivity: 3.5 mm
Video port type: HDMI
Video ports quantity: 4
