Certification: CE, FCC, RoHS & REACH
Design
Housing material: Metal
Push button: Yes
Rack mounting: No
LED indicators: Status
Product colour: Black
Hot keys: Yes
Power
Power source: DC
Input voltage: 5 V
Output current: 1 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 311 g
Height: 68 mm
Depth: 18 mm
Width: 176 mm
Performance
Video bandwidth: 60 Hz
Maximum resolution: 7680 x 4320 pixels
HDCP: Yes
HDCP version: 2.3
Data transfer rate (max): 48 Gbit/s
HD type: 8K Ultra HD
Packaging data
Package height: 70 mm
Package type: Box
Package weight: 540 g
Package depth: 130 mm
Package width: 240 mm
Packaging content
Cables included: HDMI, DC, USB Type-A to Micro USB-B
Quick installation guide: Yes
Manual: Yes
Remote control included: Yes
AC adapter included: Yes
Display
Built-in display: No
Ports & interfaces
Video port type: HDMI
DC-in jack: Yes
HDMI ports quantity: 4
Console ports: HDMI, USB A, USB C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 1
Number of computers controlled: 4
HDMI version: 2.1
Other features
Warranty period: 2 year(s)
Sustainability
Compliance certificates: REACH, RoHS, CE, Federal Communications Commission (FCC)
