Certification: CE, UKCA, FCC, RoHS, REACH
Design
Housing material: Metal
LED indicators: Yes
Product colour: Black
Power
External power adapter: Yes
Output voltage: 24 V
Power over Ethernet (PoE): Yes
Included power plug types: UK, EU, AU, US
Output current: 0.5 A
Power note: 3.5/1.35mm DC
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 70 °C
Storage temperature (T-T): -20 - 80 °C
Weight & dimensions
Receiver depth: 6.4 cm
Weight: 415 g
Receiver width: 11 cm
Transmitter width: 6 cm
Receiver height: 2.3 cm
Transmitter depth: 6.7 cm
Transmitter height: 2.3 cm
Performance
Cable types supported: Cat5, Cat5e, Cat6
Data transfer rate: 480 Mbit/s
Plug and Play: Yes
Type: Network transmitter & receiver
Maximum transfer distance: 50 m
Chipset (transmitter): NS1021
Packaging data
Package type: Box
Package height: 50 mm
Package width: 215 mm
Package volume: 600 cm³
Package depth: 155 mm
Packaging content
Cables included: USB Type-A to USB Type-B
Manual: Yes
Ports & interfaces
DC-in jack: Yes
RJ-45 ports quantity (transmitter): 1
Connector contacts plating: Gold
Ethernet LAN (RJ-45) ports: 2
RJ-45 ports quantity (receiver): 1
Contact material: Phosphor bronze
Connector material: Gold
USB 2.0 ports quantity: 5
Logistics data
Harmonized System (HS) code: 85176990
