Features HDCP: Yes Chipset: SIL9396, SIL9630 Maximum resolution: 3840 x 2160 pixels Maximum refresh rate: 60 Hz Material: Metal Product colour: Black Maximum transfer distance: 50 m Cable types supported: Cat5e, Cat6 Type: AV transmitter & receiver Bandwidth: 18 Gbit/s IR pass-through: Yes Extended display identification data (EDID): Yes HDCP pass-through: Yes
Power Input current: 1 A Operating voltage: 24 V
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 20 - 90% Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Receiver dimensions (WxDxH): 70 x 15 x 97 mm Transmitter weight: 156 g Transmitter dimensions (WxDxH): 70 x 15 x 97 mm Receiver weight: 151 g
Packaging data Package height: 130 mm Package weight: 605 g Package type: Box Package width: 220 mm Package depth: 70 mm
