Features Cable material: Copper Shield material: Aluminium Connector 1 gender: Male Colour sampling: 4:2:0 Connector 2 gender: Male Connector contacts plating: Gold Connector housing material: Polyvinyl chloride (PVC) Dolby technologies: Dolby TrueHD, DTS-HD Master Audio Cable jacket material: Polyvinyl chloride (PVC) Bending radius (min): 9.8 cm Maximum refresh rate: 60 Hz Contact material: Phosphor bronze Cable length: 7.5 m Product colour: Grey, Black 3D: Yes Connector 2: HDMI Type A (Standard) HDMI version: 2.0 Connector 1: HDMI Type A (Standard) Supported graphics resolutions: 3840 x 2160 Connector 2 form factor: Straight Data transfer rate: 10.2 Gbit/s Cable type: Round cable AWG wire size: 24 Connector 1 form factor: Straight
Operational conditions Storage temperature (T-T): -25 - 85 °C Operating temperature (T-T): -20 - 80 °C
Weight & dimensions Cable diameter: 9.8 mm Connector 1 dimensions (WxDxH): 21.4 x 41.44 x 12.7 mm Connector 2 dimensions (WxDxH): 21.4 x 41.44 x 12.7 mm
Packaging data Package type: Polybag Quantity per pack: 1 pc(s) Certification: RoHS, REACH, UL
Certificates Compliance certificates: RoHS
Logistics data Harmonized System (HS) code: 84733080
Safety warning Warnings: Avoid bending the cable sharply to avoid damaging the internal wires., Avoid contact of the cable with water or moisture., Store the cable away from heat sources.
