Technical details
Compliance certificates: REACH, RoHS, CE
Certification: CE, FCC, RoHS, REACH
Features
Chipset: GSV1001
Type: AV transmitter & receiver
Supported graphics resolutions: 1920 x 1080 (HD 1080), 3840 x 2160
Maximum resolution: 3840 x 2160 pixels
Bandwidth: 10.2 Gbit/s
Audio output channels: 7.1 channels
Cable types supported: Cat6
Maximum transfer distance: 70 m
Extended display identification data (EDID): Yes
HDCP: Yes
HDCP version: 1.4
Material: Metal
Product colour: Black
Maximum refresh rate: 60 Hz
Power
Input current: 1 A
Operating voltage: 12 V
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 90%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 130 g
Depth: 69 mm
Height: 16.5 mm
Width: 79.5 mm
Packaging data
Package height: 113 mm
Package width: 200 mm
Package weight: 414 g
Package depth: 70 mm
Packaging content
Manual: Yes
IR receiver included: Yes
AC adapter included: Yes
Ports & interfaces
RJ-45 input ports: 1
Remote (IR) input: 1
Connectivity technology: Wired
HDMI in: 1
RJ-45 output ports: 1
HDMI version: 1.4
Remote (IR) output: 1
Number of HDMI outputs: 2
Safety warning
Warnings: Keep away from children., The product may contain electronic components. Do not dispose of in the normal household waste., Do not dismantle the appliance, it may contain small parts that can cause damage., Do not expose to extreme temperatures or moisture., Do not connect devices with higher power consumption than recommended., Store in a dry place, avoid contact with water.
