Features Connector 2 form factor: Straight Connector 2 gender: Female Connector 1 gender: Male Connector contacts plating: Gold Connector material: Nickel Cable jacket material: Polyvinyl chloride (PVC) Maximum data transfer rate: 5 Gbit/s, 5000 Mbit/s Connector 1 form factor: Straight Connector 1: USB A Conductor material: Tinned copper Connector shielding: Yes AWG wire size: 24/24/20 Cable type: Round cable Connector 2: USB A Connector shield material: Aluminium USB version: USB 3.2 Gen 1 (3.1 Gen 1) Product colour: Black Transmission medium: Twisted pair Connector housing material: Plastic Contact material: Brass
Power Power note: 2.5/0.7mm DC
Operational conditions Operating temperature (T-T): 0 - 50 °C Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Cable diameter: 7 mm Weight: 750 g Cable length: 8 m Connector 2 dimensions (WxDxH): 20 x 80 x 13 mm Bend radius (min): 3.6 cm Connector 1 dimensions (WxDxH): 15 x 49 x 8 mm
Packaging data Package width: 240 mm Package height: 200 mm Package type: Box Package weight: 900 g Package depth: 70 mm
Packaging content Quantity per pack: 1 pc(s) Manual: Yes
Logistics data Harmonized System (HS) code: 84733080
