Features Maximum resolution: 3840 x 2160 pixels DisplayPort version: 1.2 Connector 1 gender: Male Connector 2 gender: Female Jacket material: Nylon/Polyvinyl Chloride (PVC) Data transfer rate: 21.6 Gbit/s Colour depth: 8 bit Cable length: 157 m Refresh rate at maximum resolution: 60 Hz Power source: USB Product colour: Black Connector 2: DisplayPort Maximum refresh rate: 60 Hz Cable type: Round cable Connector 1 form factor: Straight Chipset: LT6711A Connector 1: HDMI Type A (Standard) Colour sampling: 4:4:4 HDMI version: 2.0 Connector 2 form factor: Straight Connector housing material: Acrylonitrile butadiene styrene (ABS) Bend radius (min): 2.5 cm
Operational conditions Operating relative humidity (H-H): 20 - 70% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -20 - 45 °C
Weight & dimensions Weight: 50 g Connector 1 dimensions (WxDxH): 30 x 8 x 17 mm Connector 2 dimensions (WxDxH): 71 x 12 x 31 mm
Packaging data Package type: Polybag Package height: 20 mm Package weight: 60 g Package width: 174 mm Package depth: 194 mm
Packaging content Quantity per pack: 1 pc(s)
Certificates Compliance certificates: REACH, Federal Communications Commission (FCC), UKCA, RoHS, CE
