Technical details Sustainability compliance: Yes Compliance certificates: Federal Communications Commission (FCC), REACH, UKCA, RoHS, CE
Features Video compression formats: H.265 HDCP: Yes Bandwidth: 6.75 Gbit/s Chipset: SSC337DE - SSD203D HDCP version: 1.4 Material: Metal Type: AV transmitter & receiver Cable types supported: Cat5e, Cat6 Maximum transfer distance: 150 m Supported video modes: 1080p Maximum resolution: 1920 x 1080 pixels Maximum refresh rate: 60 Hz Product colour: Black Infrared (IR) frequency range: 20 - 60 kHz
Power Operating voltage (receiver): 5 V Output current: 1 A Operating voltage (transmitter): 5 V
Operational conditions Operating temperature (T-T): -10 - 50 °C Operating relative humidity (H-H): 20 - 90% Storage temperature (T-T): -20 - 60 °C
Weight & dimensions Transmitter dimensions (WxDxH): 88 x 61.2 x 16.5 mm Receiver dimensions (WxDxH): 88 x 61.2 x 16.5 mm Receiver weight: 530 g Transmitter weight: 530 g
Packaging data Package height: 70 mm Package weight: 730 g Package width: 220 mm Quantity per pack: 1 pc(s) Package depth: 130 mm
Packaging content Manual: Yes
Ports & interfaces Video in: 1 RJ-45 output ports: 1 RJ-45 input ports: 1 Number of HDMI outputs: 2 Remote (IR) input: 1 HDMI in: 1 Remote (IR) output: 1 Video out: 2 DC-in jack: Yes Connectivity technology: Wired
