Certification: CE, UKCA, FCC, RoHS, REACH & California Proposition 65
Design
Product colour: Black
LED indicators: Status
Rack mounting: No
Hot keys: Yes
Housing material: Metal
Push button: Yes
Power
Output current: 2 A
Input voltage: 5 V
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -10 - 60 °C
Operating relative humidity (H-H): 5 - 80%
Weight & dimensions
Weight: 689 g
Width: 231 mm
Depth: 108 mm
Height: 23 mm
Performance
HD type: 4K Ultra HD
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Video bandwidth: 60 Hz
Packaging data
Package weight: 988 g
Package type: Box
Package depth: 238 mm
Package height: 55 mm
Package width: 292 mm
Packaging content
Quick installation guide: Yes
Manual: Yes
Cables included: DC
Display
Built-in display: No
Ports & interfaces
HDMI ports quantity: 4
Console ports: 3.5mm headphone, USB A, HDMI
USB 2.0 Type-B ports quantity: 4
Audio connections: Yes
Mouse port type: USB
Headphone outputs: 2
Console USB ports quantity: 3
HDMI version: 2.0
Keyboard port type: USB
Video port type: HDMI
Number of computers controlled: 4
Logistics data
Harmonized System (HS) code: 85176200
Safety warning
Warnings: Ensure the unit is adequately ventilated during operation., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
