Design Product colour: White Number of fans: 3 fan(s) Base plate material: Copper Radiator material: Aluminum Fan connector: 4-pin Illumination LED: Yes Illumination colour: Multi LED connector type: 3-pin
Power Fan current: 0.33 A LED voltage: 5 V Pump current: 350 mA Fan voltage: 12 V Pump voltage: 12 V
Weight & dimensions Package weight: 2.45 kg Weight: 2 kg Package width: 167 mm Package height: 142 mm Height: 66 mm Depth: 398 mm Tube length: 45 cm Radiator depth: 39.8 cm Fan dimensions (W x D x H): 120 x 120 x 25 mm Radiator width: 12 cm Radiator height: 3.8 cm Package depth: 414 mm Tube diameter: 1.24 cm Width: 120 mm VRM fan diameter: 9.1 cm Tube inner diameter: 6 mm
Performance Type: Liquid cooling kit Operating temperature (T-T): 0 - 40 °C Supported processor sockets: Socket AM4, LGA 1700, Socket AM5, Intel LGA1851 Fan speed (min): 600 RPM Fan diameter: 12 cm Pulse-width modulation (PWM) support: Yes Suitable location: Processor Airflow: 131 m³/h Fan static pressure: 6.9 mmH2O Pump motor speed (max): 2800 RPM Fan speed (max): 3000 RPM Maximum airflow: 77 cfm Pump motor speed (min): 800 RPM Bearing type: Fluid Dynamic Bearing (FDB) Quantity per pack: 1 pc(s) VRM fan speed (max): 2500 RPM VRM fan speed (min): 400 RPM
