Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Processor socket: LGA 1851 (Socket V1)
Graphics
On-board graphics card: No
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64
Motherboard form factor: ATX
Product colour: Black
PC health monitoring: Fan, Voltage, Temperature
Motherboard chipset: Intel Z890
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Memory
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8800 MHz
Supported memory clock speeds: 6000, 6800 MHz, 6400, 7600, 7800, 8000, 8600, 8400, 8266, 6600, 7000, 8200, 5600 MHz, 7200, 7400, 6200, 7950, 7900, 5800
Supported memory module capacities: 1GB, 12GB, 16GB, 64GB, 8GB, 32GB, 48GB, 2GB, 4GB, 40GB, 24GB
Maximum internal memory: 256 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Height: 35 mm
Network
Wi-Fi: Yes
Ethernet LAN: Yes
WLAN controller model: Intel Wi-Fi 6E AX211
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, Wi-Fi 4 (802.11n)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Bluetooth: Yes
Internal I/O
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
12V power connector: Yes
Total number of SATA connectors: 4
TPM connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
BIOS
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS button: Yes
Packaging data
Package height: 80 mm
Package width: 335 mm
Package depth: 270 mm
Package weight: 2.02 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
Number of HDDs supported: 7
RAID levels: 10, 1, 0, 5
Number of storage drives supported: 4
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Rear panel I/O ports
HDMI ports quantity: 1
Thunderbolt ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Microphone in: Yes
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
S/PDIF out port: Yes
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 3
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
Battery
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Lithium weight per battery: 0.07 g
Other features
Weight: 1.78 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Do not open or modify the motherboard to prevent damage., In case of installation problems, contact a qualified service technician., When disposing of the product, follow local regulations for the recycling of electronics.
