Technical details
Compliance certificates: RoHS, CE, UKCA, REACH, Federal Communications Commission (FCC)
Warranty period: 3 year(s)
Power
USB cable length: 0.5 m
Power source type: USB
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 0 - 85%
Weight & dimensions
Width: 60 mm
Depth: 269 mm
Height: 30 mm
Weight: 182 g
Network
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
Performance
Plug and Play: Yes
Compatible memory cards: MicroSD (TransFlash), SD
Maximum digital resolution: 3840 x 2160 pixels
Data transfer rate: 5 Gbit/s
Card reader integrated: Yes
Maximum refresh rate: 60 Hz
Housing material: Aluminium
LED indicators: Yes
Product colour: Grey
HD type: 4K Ultra HD
Packaging data
Package weight: 260 g
Package width: 310 mm
Quantity per pack: 1 pc(s)
Package height: 110 mm
Package depth: 35 mm
Packaging content
Manual: Yes
Software
Windows operating systems supported: Windows 10, Windows 8.1, Windows 11, Windows 8, Windows 7
Mac operating systems supported: Yes
Other operating systems supported: ChromeOS
Mobile operating systems supported: Android
Ports & interfaces
HDMI ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity: 1
Microphone in: No
USB Power Delivery up to: 100 W
HDCP version: 2.2
USB Power Delivery (USB PD): Yes
USB Type-C DisplayPort Alternate Mode: Yes
HDCP: Yes
DisplayPort version: 1.4
Connectivity technology: Wired
Logistics data
Products per master (outer) case: 20 pc(s)
Master (outer) case width: 355 mm
Master (outer) case gross weight: 5.2 kg
Master (outer) case height: 250 mm
Master (outer) case length: 395 mm
