Technical details
Compliance certificates: REACH, Federal Communications Commission (FCC), RoHS, CE, UKCA
Warranty period: 3 year(s)
Features
HDCP version: 2.3
Maximum resolution: 3840 x 2160 pixels
LED indicators: Yes
Supported video modes: 576i, 480p, 1080p, 720p, 1080i
Plug and Play: Yes
Maximum operating distance: 5 m
Data transfer rate: 18 Gbit/s
Housing material: Plastic
HDCP: Yes
Product colour: Black
3D: Yes
Colour depth: 36 bit
Cable length: 0.8 m
HD type: 4K Ultra HD
Downscaler: Yes
Bandwidth: 600 MHz
Dolby technologies: Dolby TrueHD, DTS-HD Master Audio
Number of displays supported: 4
High Dynamic Range (HDR) supported: Yes
Extended display identification data (EDID): Yes
Power
AC input voltage: 5 V
Power consumption (typical): 5 W
USB powered: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -20 - 80 °C
Operating temperature (T-T): 0 - 70 °C
Weight & dimensions
Height: 15 mm
Weight: 87 g
Depth: 136 mm
Width: 62 mm
Packaging data
Package type: Box
Package weight: 260 g
Quantity per pack: 1 pc(s)
Packaging content
Cables included: USB Type-A to Micro-USB Type-B
Manual: Yes
Ports & interfaces
Video ports quantity: 5
Video port type: HDMI
Video out: 4x HDMI
HDMI version: 2.0
