Technical details
Compliance certificates: RoHS
Certification: CTS 1.4a
CE
FCC
RoHS2
Features
HD type: 4K Ultra HD
Connector contacts plating: Gold
Maximum resolution: 3840 x 2160 pixels
3D: Yes
HDCP: Yes
Housing material: Plastic
Supported video modes: 480i, 720p, 1080i, 480p, 1080p, 2160p, 576i, 576p
Windows operating systems supported: Yes
Product colour: Black
Power
Input current: 2 A
AC input voltage: 5 V
USB powered: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 96%
Weight & dimensions
Weight: 50 g
Depth: 255 mm
Width: 50 mm
Height: 11 mm
Packaging content
Cables included: Micro-USB
Ports & interfaces
DC-in jack: Yes
Video port type: DisplayPort
Video ports quantity: 2
Video out: 2x DisplayPort
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Avoid contact with liquid to prevent damage to the unit., Do not open the appliance housing to avoid electric shock., Ensure that the product is used in accordance with the manufacturer's recommendations.
