Design
Radiator material: Aluminum
LED connector type: 3-pin
Product colour: Black
Illumination LED: Yes
Fan connector: 4-pin
Illumination colour: Multi
Number of heat pipes: 4
Number of fans: 1 fan(s)
Power
LED voltage: 5 V
Fan current: 0.28 A
Fan voltage: 12 V
Power supply: 3.36 W
Thermal Design Power (TDP): 220 W
Weight & dimensions
Package width: 143 mm
Package height: 194 mm
Weight: 505 g
Height: 154 mm
Package depth: 98 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Depth: 68 mm
Width: 120 mm
Performance
Supported processor sockets: LGA 1156 (Socket H), LGA 1700, Socket AM4, LGA 1366 (Socket B), LGA 1851, LGA 1200 (Socket H5), LGA 1151 (Socket H4), LGA 1150 (Socket H3), Socket AM5, LGA 1155 (Socket H2)
Suitable location: Processor
Quantity per pack: 1 pc(s)
Fan speed (min): 800 RPM
Type: Air cooler
Maximum air pressure: 1.31 mmH2O
Pulse-width modulation (PWM) support: Yes
Minimum air pressure: 0.79 mmH2O
Fan noise level (max): 28 dB
Fan noise level (min): 9 dB
Fan's mean time to failure (MTTF): 60000 h
Fan speed (max): 2000 RPM
Maximum airflow: 78 cfm
Fan diameter: 12 cm
Bearing type: Hydraulic
Packaging content
LED controller interface: SATA
Package type: Box
LED controller: Yes
RGB controller included: Yes
Mounting kit: Yes
Manual: Yes
Other features
Thermal grease: Yes
