Design
Base plate material: Copper
Illumination colour: Multi
Number of heat pipes: 6
Display type: LCD
Fan connector: 4-pin
Illumination LED: Yes
Radiator material: Aluminum
Number of fans: 1 fan(s)
Fins material: Aluminium
Product colour: Black
Power
LED voltage: 5 V
Fan voltage: 12 V
Fan power consumption: 6 W
Fan current: 0.5 A
Thermal Design Power (TDP): 300 W
Weight & dimensions
Depth: 72 mm
Width: 122 mm
Package width: 143 mm
Package depth: 98 mm
Fan dimensions (W x D x H): 120 x 25 x 120 mm
Package height: 194 mm
Height: 156 mm
Weight: 542 g
Performance
Pulse-width modulation (PWM) support: Yes
Suitable location: Processor
Fan speed (min): 800 RPM
Maximum airflow: 74 cfm
Bearing type: Hydraulic
Fan noise level (max): 28 dB
Quantity per pack: 1 pc(s)
Fan's mean time to failure (MTTF): 60000 h
Fan speed (max): 2600 RPM
Minimum air pressure: 0.85 mmH2O
Fan noise level (min): 9 dB
Fan diameter: 12 cm
Type: Air cooler
Maximum air pressure: 1.42 mmH2O
Supported processor sockets: LGA 1156 (Socket H), LGA 1700, Socket AM4, LGA 1366 (Socket B), LGA 1150 (Socket H3), Socket AM5, LGA 1200 (Socket H5), LGA 1851, LGA 1151 (Socket H4), LGA 1155 (Socket H2)
Packaging content
Manual: Yes
Package type: Box
Other features
Anti-vibration system: Yes
Thermal grease: Yes
Built-in display: Yes
