Design
Product colour: Black
Fan location: Top
Cooling type: Active
Number of fans: 1 fan(s)
On/off switch: Yes
Fan diameter: 14 cm
Power
Number of +12V rail(s): 1
AC input voltage: 220 - 240 V
Combined power (+5Vsb): 12.5 W
Power protection features: Short circuit, Over voltage, Over power, Overload, No load operation, Under voltage, Over current, Over total voltage
Max output current (+5V): 20 A
Efficiency: 90%
Combined power (+3.3V): 150 W
Power factor: 0.9
Max output current (-12V): 0.3 A
Combined power (+5V): 150 W
Combined power (-12V): 3.6 W
Max output current (+3.3V): 20 A
Combined power (+12V): 1000 W
Max output current (+5Vsb): 2.5 A
Max output current (+12V): 83.3 A
Total power: 1000 W
Input current: 15 A
AC input frequency: 47 - 63 Hz
Power Factor Correction (PFC) type: Active
Weight & dimensions
Height: 85 mm
Depth: 160 mm
Weight: 1.75 kg
Width: 150 mm
Performance
Power supply unit (PSU) form factor: ATX
Purpose: PC
80 PLUS certification: 80 PLUS Gold
Noise level: 14 dB
Bearing technology: FDB
Packaging data
Package depth: 136 mm
Package type: Box
Package height: 206 mm
Package width: 258 mm
Packaging content
Cables included: CPU, PCIe, Peripheral (Molex), SATA
Certificates
Compliance certificates: RoHS, CE, TÜV mark
Ports & interfaces
Number of EPS connectors: 2
Number of SATA power connectors: 6
EPS power connector (4+4 pin): Yes
CPU power connector (4+4 pin): Yes
Cabling type: Fully-Modular
ATX Power connector (24-pin): Yes
Motherboard power connector: 24-pin ATX
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 2
