Design Number of fans: 1 fan(s) Fan location: Top Product colour: Black Cooling type: Active Fan diameter: 12 cm
Power Max output current (+5V): 18 A Max output current (+3.3V): 18 A Power protection features: Under voltage, Over current, Over power, Short circuit, Over voltage Max output current (+12V): 45.5 A Max output current (+5Vsb): 2.5 A Combined power (-12V): 3.6 W AC input frequency: 47 - 63 Hz Efficiency: 90% Total power: 550 W Input current: 5 A Max output current (-12V): 0.3 A AC input voltage: 220 - 240 V Combined power (+5Vsb): 12.5 W Combined power (+3.3V): 100 W Power Factor Correction (PFC) type: Active Combined power (+12V): 546 W Combined power (+5V): 100 W
Weight & dimensions Height: 85 mm Depth: 145 mm Weight: 1.4 kg Width: 150 mm
Performance 80 PLUS certification: 80 PLUS Bronze Purpose: PC Noise level: 12 dB Power supply unit (PSU) form factor: ATX
Packaging data Package weight: 1.6 kg Package width: 205 mm Package depth: 240 mm Package height: 125 mm
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 1 CPU power connector (4+4 pin): Yes Cabling type: Non-Modular Motherboard power connector: 24-pin ATX Number of SATA power connectors: 4
