Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series
Processor manufacturer: AMD
Maximum internal memory supported by processor: 192 GB
Processor socket: Socket AM5
Graphics
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0
Features
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Product colour: Bronze
Motherboard chipset: AMD A620
Memory
ECC сompatibility: Non-ECC
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Unbuffered memory: Yes
Supported memory clock speed (max): 7600 MHz
Supported memory module capacities: 12GB, 16GB, 32GB, 48GB, 2GB, 4GB, 1GB, 8GB
Supported memory clock speeds: 7600, 4800, 6000, 6400, 6800 MHz, 6200, 7000, 5600 MHz, 7200, 5200
Maximum internal memory: 192 GB
Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 244 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Internal I/O
Front panel connector: Yes
CPU fan connector: Yes
TPM connector: Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
USB 2.0 connectors: 1
Number of SATA III connectors: 4
Total number of SATA connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
12V power connector: Yes
RGB LED pin header: Yes
BIOS
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 54 mm
Package depth: 265 mm
Package weight: 1.07 kg
Package width: 265 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Cables included: SATA
Storage controllers
RAID levels: 1, 0, 10
Number of storage drives supported: 4
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of HDDs supported: 1
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB connector type: USB Type-A, USB Type-C
HDMI version: 2.1
Microphone in: Yes
PS/2 ports quantity: 1
Headphone outputs: 3
HDMI ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x1 slots: 1
PCI Express x16 slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage.
