Design
LED indicators: Power, WLAN
Product type: Tabletop router
Wall mountable: Yes
Product colour: Black
Power
Power source type: DC
Security
DMZ support: Yes
Access Control List (ACL): Yes
Firewall security: SPI Firewall, IP and MAC Address Binding
Firewall: Yes
MAC address filtering: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Management features
WPS push button: Yes
Reset button: Yes
Weight & dimensions
Width: 208.8 mm
Depth: 171.6 mm
Height: 41.7 mm
Network
Ethernet LAN: Yes
Port triggering: Yes
Port forwarding: Yes
Ethernet LAN interface type: Gigabit Ethernet
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.11b, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Wireless radio: Yes
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Packaging data
Cables included: LAN (RJ-45)
AC adapter included: Yes
Quick installation guide: Yes
Wireless LAN features
WLAN data transfer rate (second band): 574 Mbit/s
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max): 1775 Mbit/s
WLAN data transfer rate (first band): 1201 Mbit/s
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Protocols
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
DHCP client: Yes
Ports & interfaces
USB port: No
Memory card slot(s): No
Ethernet LAN (RJ-45) ports: 4
Antenna
Antenna gain level (max): 5 dBi
Antennas quantity: 4
Detachable antenna(s): No
Antenna type: External
WAN connection
SIM card slot: No
Ethernet WAN: Yes
3G/4G USB modem compatibility: No
Mobile network
3G: No
4G: No
