Receiver sensitivity: 2.4GHz:
1MBit/s: -100 @ 26dBm Tx
11MBit/s: -94 @ 26dBm Tx
6MBit/s: -96 @ 26dBm Tx
54MBit/s: -78 @ 23dBm Tx
MCS0: -96 @ 26dBm Tx
MCS7: -73 @ 22dBm Tx
5GHz:
6MBit/s: -96 @ 26dBm Tx
54MBit/s: -80 @ 21dBm Tx
MCS0: -96 @ 26dBm Tx
MCS7: -75 @ 20dBm Tx
MCS9: -70 @ 18dBm Tx
Features
2.4 GHz: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Frequency band: 2.412 - 2.484, 5.15 - 5.875 GHz
Maximum data transfer rate: 867 Mbit/s
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 300 Mbit/s
Networking standards: IEEE 802.3at, IEEE 802.11a, IEEE 802.11ac, IEEE 802.3af, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate (5 GHz): 867 Mbit/s
Design
Product colour: White
Placement: Ceiling, Wall
LED indicators: Yes
Internal: No
Power
Power consumption (max): 13 W
Output voltage: 57 V
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Active PoE, Passive PoE
DC voltage range: 17 - 57 V
Operational conditions
Operating temperature (T-T): -40 - 50 °C
Weight & dimensions
Depth: 30 mm
Width: 136 mm
Height: 136 mm
Performance
Processor frequency: 716 MHz
Processor model: IPQ4018
Operating system installed: RouterOS
Internal memory: 128 MB
Flash memory: 16 MB
Built-in processor: Yes
Packaging content
AC adapter included: Yes
Mounting kit: Yes
PoE adapter included: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
Antenna
Antenna type: Internal
Antennas quantity: 4
Antenna gain level (max): 2.5 dBi
Antenna features: Integrated antenna
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Make sure the unit is stably mounted and ventilated., Do not open the appliance - risk of electric shock., Do not use in damp conditions.
