Receiver sensitivity: 802.11g: -96dBm @ 6Mbit/s to -80dBm @ 54Mbit/s
802.11n: -96dBm @ MCS0 to -78dBm @ MCS7
Features
Networking standards: IEEE 802.3, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b, IEEE 802.3u
Modulation: DQPSK, DBPSK, OFDM, 64-QAM, DSSS, CCK, 16-QAM, BPSK, QPSK
Frequency band: 2.4 GHz
2.4 GHz: Yes
Ethernet LAN data rates: 10, 100
Design
Product colour: White
Internal: No
Housing material: Plastic
LED indicators: Yes
Power
Power consumption (max): 7 W
AC input voltage: 7 - 31 V
Power over Ethernet (PoE): Yes
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Weight & dimensions
Height: 29 mm
Depth: 113 mm
Width: 138 mm
Performance
Internal memory: 128 MB
Built-in processor: Yes
Internal memory type: DDR2
Processor model: Qualcomm Atheros AR9344-DC3A
Processor frequency: 600 MHz
Ports & interfaces
Ethernet LAN (RJ-45) ports: 5
USB connector type: USB Type-A
USB 2.0 ports quantity: 1
Antenna
Antenna gain level (max): 2.5 dBi
Antenna type: Internal
Logistics data
Harmonized System (HS) code: 85176990
