Receiver sensitivity: 802.11g: -96dBm @ 6Mbit/s to -80dBm @ 54Mbit/s
802.11n: -96dBm @ MCS0 to -78dBm @ MCS7
Features
Modulation: 64-QAM, DSSS, DQPSK, DBPSK, 16-QAM, BPSK, QPSK, CCK, OFDM
Frequency band: 2.4 GHz
Ethernet LAN data rates: 100, 10
Networking standards: IEEE 802.3, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.11b
2.4 GHz: Yes
Design
LED indicators: Yes
Internal: No
Product colour: White
Housing material: Plastic
Power
Power over Ethernet (PoE): Yes
Power consumption (max): 7 W
AC input voltage: 7 - 31 V
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Weight & dimensions
Width: 138 mm
Height: 29 mm
Depth: 113 mm
Performance
Processor model: Qualcomm Atheros AR9344-DC3A
Processor frequency: 600 MHz
Internal memory: 128 MB
Built-in processor: Yes
Internal memory type: DDR2
Ports & interfaces
USB connector type: USB Type-A
Ethernet LAN (RJ-45) ports: 5
USB 2.0 ports quantity: 1
Antenna
Antenna gain level (max): 2.5 dBi
Antenna type: Internal
Logistics data
Harmonized System (HS) code: 85176990
