Technical details Warranty period: 2 year(s) Compliance certificates: CE
Design Fins material: Aluminium Base plate material: Copper Number of fans: 1 fan(s) Number of heat pipes: 4 Fan connector: 4-pin Product colour: Black
Power Rated voltage: 12 V Thermal Design Power (TDP): 190 W
Weight & dimensions Width: 73 mm Package height: 187 mm Height: 153 mm Package weight: 755 g Depth: 120 mm Heat pipes diameter: 6 mm Weight: 650 g Package width: 100 mm Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance Supported processor sockets: LGA 1851, LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5, LGA 1366 (Socket B) Noise level (high speed): 28 dB Type: Air cooler Rotational speed (max): 2000 RPM Bearing type: Fluid Dynamic Bearing (FDB) Suitable location: Processor Airflow: 75 m³/h Fan diameter: 12 cm Quantity per pack: 1 pc(s) Pulse-width modulation (PWM) support: Yes Fan's mean time to failure (MTTF): 100000 h
Packaging content Screws included: Yes Mounting kit: Yes Number of screws: 8 CPU bracket(s): Yes Installation instruction: Yes
Other features RGB LED pin header: Yes Machined aluminium design: Yes Thermal grease: Yes
Safety warning Warnings: Ensure that the unit is switched off before starting to assemble or dismantle the cooling unit., Take appropriate precautions during installation to avoid damage to computer components., Do not touch the fan during operation.
