Motherboard - ASRock B860 Pro RS WiFi

Processor
Processor socket: LGA1851
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Compatible processor series: Intel Core Ultra (Series 2)

Features
Motherboard chipset family: Intel
Motherboard form factor: ATX
Motherboard chipset: Intel B860
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 11
Audio output channels: 7.1 channels
Operating system architecture: 64-bit

Memory
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory clock speed (max): 8666 MHz

Weight & dimensions
Width: 305 mm
Depth: 244 mm

Network
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
Bluetooth: Yes
Wi-Fi: Yes
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
Bluetooth version: 5.3
MU-MIMO: Yes

Internal I/O
Number of chassis fan connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 2
USB Type-C ports quantity: 1
RGB LED pin header: Yes

BIOS
BIOS type: UEFI AMI

Storage controllers
Supported RAID configuration: 0,1,5,10
RAID rebuild: Yes

Rear panel I/O ports
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
Line-in: Yes
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Number of Wi-Fi antenna ports: 2
MIC input: 1
Number of USB 2.0 Type-A ports: 2

Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1

Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
