Processor
Maximum number of SMP processors: 1
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen™ 7000 Series, AMD Ryzen™ 9000 Series, AMD Ryzen™ 8000 Series
Processor socket: Socket AM5
Features
Motherboard chipset: AMD X870
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Operating system architecture: 64-bit
Motherboard form factor: ATX
Audio chip: Realtek ALC4080
Memory
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Supported memory clock speed (max): 8000+ MHz
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Unbuffered memory: Yes
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Bluetooth: Yes
Bluetooth version: 5.4
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
LAN controller: Killer E3100
Internal I/O
Number of SATA III connectors: 4
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Front panel audio connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive interfaces: Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)
Rear panel I/O ports
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
S/PDIF out port: Yes
Line-out: Yes
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 2
Wi-Fi antenna socket: Yes
USB 2.0 connectors: 4
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
