Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Features
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard chipset: AMD B650
PC health monitoring: Voltage, Fan, Temperature
Motherboard form factor: micro ATX
Power source type: ATX
Windows operating systems supported: Windows 10 x64, Windows 11
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory clock speeds: 4800, 5200, 6400, 6200, 6000, 4400, 5600
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 6400 MHz
ECC сompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Weight & dimensions
Height: 35 mm
Depth: 225 mm
Width: 240 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
WLAN controller model: Realtek RTL8852CE
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
CPU fan connector: Yes
TPM connector: Yes
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 3
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 2
Number of EPS power connectors (8-pin): 1
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package height: 68 mm
Package weight: 1.21 kg
Package depth: 268 mm
Package width: 270 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of storage drives supported: 5
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
Headphone outputs: 1
HDMI version: 2.1
PS/2 ports quantity: 1
Line-in: Yes
WiFi-AP antenna jack: 2
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
1st M.2 largest key size: 2580
1st M.2 highest PCI Express generation: 4.0
Battery
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Other features
Weight: 720 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
