Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Graphics
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
HDCP: Yes
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Power source type: ATX
Cooling type: Passive
Motherboard form factor: micro ATX
PC health monitoring: Voltage, Water cooling, Fan, Temperature
Product colour: Dark brown
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard chipset: AMD B840
Memory
Number of memory slots: 4
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 8200 MHz
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 5200, 6200, 6400, 4800, 6000, 4400, 5800, 5600, 6600, 7400, 8000, 7000, 8200 MHz, 6800, 7950, 7900, 7600, 7800, 7200 MHz
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Height: 35 mm
Width: 244 mm
Depth: 244 mm
Network
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
WLAN controller model: Realtek RTL8852CE
Wi-Fi standards: 802.11g, 802.11a, 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Bluetooth version: 5.3
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth: Yes
LAN controller: Realtek RTL8125
Internal I/O
12V power connector: Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 4
RGB LED pin header: Yes
TPM connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Front panel connector: Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
Number of water pump connectors: 2
USB 2.0 connectors: 2
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging data
Package width: 270 mm
Package weight: 1.59 kg
Package height: 68 mm
Package depth: 268 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Screws included: Yes
Antenna included: Yes
Storage controllers
RAID levels: 1, 10, 0
RAID support: Yes
Number of storage drives supported: 6
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
USB 2.0 ports quantity: 4
PS/2 ports quantity: 1
Microphone in: Yes
Line-in: Yes
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
DisplayPort version: 1.4
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2580
2nd M.2 largest key size: 22110
Battery
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery type: CR2032
Lithium weight per battery: 0.07 g
Other features
Weight: 1.5 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
