Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
PC health monitoring: Fan, Water cooling, Temperature, Voltage
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Product colour: Dark brown
Motherboard chipset: Intel H810
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Cooling type: Passive
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Power source type: ATX
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Unbuffered memory: Yes
Maximum internal memory: 128 GB
Supported memory clock speeds: 6400, 5600
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Supported memory clock speed (max): 6400 MHz
Memory channels: Dual-channel
Weight & dimensions
Depth: 215 mm
Height: 35 mm
Width: 244 mm
Network
LAN controller: Realtek RTL8111H
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of RGB LED pin headers: 2
USB 2.0 connectors: 1
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel connector: Yes
Front panel audio connector: Yes
TPM connector: Yes
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
Serial port headers: 1
Number of chassis fan connectors: 2
Number of SATA III connectors: 4
CPU fan connector: Yes
RGB LED pin header: Yes
BIOS
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package width: 265 mm
Package height: 54 mm
Package depth: 265 mm
Package weight: 872 g
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
RAID support: Yes
RAID levels: 10, 1, 5, 0
Number of storage drives supported: 5
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPort version: 2.1
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
Line-in: Yes
Microphone in: Yes
HDMI version: 2.1
PS/2 ports quantity: 1
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 5
Expansion slots
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Other features
Weight: 790 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
