Processor
Processor manufacturer: Intel
Compatible processor series: Intel Xeon 6
Number of processors supported: 2
Processor socket: FCLGA 4710
Graphics
Parallel processing technology support: Not supported
On-board graphics card model: Aspeed AST2600
Compatible operating systems: Windows Server, Red Hat Enterprise Linux server, SUSE Linux Enterprise server, Ubuntu, Citrix Hypervisor, XenServer, VMware ESXi
Features
Component for: Server
Motherboard chipset: System on Chip
Motherboard form factor: Extended ATX
Memory
Number of DIMM slots: 16
Supported memory types: DDR5 RDIMM/MRDIMM
Memory channels: Octa-channel
Maximum internal memory: 2 TB
Supported memory clock speeds: 6400 MHz, 8000
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 8 - 80%
Storage relative humidity (H-H): 20 - 95%
Operating temperature (T-T): 10 - 40 °C
Weight & dimensions
Width: 305 mm
Depth: 330 mm
Internal I/O
TPM connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 12
Storage controllers
Supported storage drive interfaces: PCI Express, SATA III
Rear panel I/O ports
COM ports quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 4
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 slots: 6
