Power
Battery technology: Lithium Polymer (LiPo)
Operational conditions
Operating relative humidity (H-H): 5 - 85%
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Weight: 224 g
Certification: EMC FCC Part 15 Class B, ICES 003 Class B,
IEC 60601-1-2 RoHS 2002/95/EEC
Performance
LED indicators: Charging, Power
International Protection (IP) code: IP54
Product colour: Black
Housing material: Plastic
Packaging data
Cables included: RS-232
Ports & interfaces
Bluetooth: Yes
Standard interfaces: RS-232, RS-485, USB, Keyboard wedge
Cable length: 1.8 m
Other features
Safety: C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950- 1 LED Class 1
Dimensions (WxDxH): 70 x 186 x 98 mm
Shockproof: No
Light source: LED
Logistics data
Harmonized System (HS) code: 84716070
Decoding standards: UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN
8, EAN-13/JAN 13, Bookland EAN, Bookland
ISBN Format, UCC Coupon Extended Code,
ISSN EAN
Code 128 Including GS1-128, ISBT
128, ISBT Concatenation, Code 39 including
Trioptic Code 39, Convert Code 39 to Code
32 (Italian Pharmacy Code), Code 39 Full
ASCII Conversion Code 93 Code 11 Matrix
2 of 5 Interleaved 2 of 5 (ITF) Discrete 2
of 5 (DTF) Codabar (NW - 7) MSI Chinese
2 of 5 IATA
Inverse 1D (except all GS1
DataBars) GS1 DataBar including GS1
DataBar-14, GS1 DataBar Limited, GS1
Scanning
Maximum range: 6 m
Read rate (max): 547 reads/s
Light levels (direct sunlight): 0 - 108 lx
Wavelength: 612 nm
Yaw reading angle: 0 - 65°
Maximum scan width: 10 cm
Tilt angle range: 0 - 35°
Pitch reading angle: 0 - 65°
Tilt reading angle: 0 - 45°
