Processor
Maximum number of SMP processors: 1
Compatible processor series: AMD Ryzen 3000 Series
Processor manufacturer: AMD
Processor socket: Socket AM4
Graphics
Maximum resolution: 4096 x 2160 pixels
Features
Motherboard chipset family: AMD
Motherboard chipset: AMD A520
Audio chip: Realtek ALC892
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Number of mounting holes: 6
Component for: PC
Power source type: ATX
Memory
Supported memory clock speeds: 2133 MHz, 2400, 2800, 2667, 3733, 4400 MHz, 3066, 3000, 3866, 4133, 4000, 3466, 2933, 3600, 3200, 4266 MHz, 4466, 1866
Maximum internal memory: 64 GB
Unbuffered memory: No
Memory slots type: DIMM
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Height: 65 mm
Width: 244 mm
Depth: 210 mm
Network
LAN controller: Realtek 8111H
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
CPU fan connector: Yes
Total number of SATA connectors: 4
Number of chassis fan connectors: 1
Chassis intrusion connector: Yes
Number of SATA III connectors: 4
Front panel connector: Yes
Storage controllers
Supported storage drive interfaces: PCI Express 3.0, SATA
Supported storage drive types: HDD & SSD
RAID levels: 1, 10, 0
Rear panel I/O ports
DisplayPorts quantity: 1
USB 2.0 ports quantity: 2
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
Microphone in: Yes
Expansion slots
PCI Express x16 slots: 1
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 1
Other features
Weight: 698 g
Logistics data
Harmonized System (HS) code: 84733020
