Processor
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Maximum number of SMP processors: 1
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 3000 Series
Graphics
Maximum resolution: 4096 x 2160 pixels
Maximum graphics card memory: 16000 MB
Parallel processing technology support: Not supported
Features
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Number of mounting holes: 8
Motherboard chipset: AMD B550
Product colour: Black
Audio chip: Realtek ALC892
Memory
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 3000, 3466, 4133, 4000, 2667, 3733, 4400, 3066, 2400, 2800, 3200, 4266, 1866, 3866, 2933 MHz, 3600, 2133
ECC сompatibility: ECC & Non-ECC
Unbuffered memory: Yes
Maximum internal memory: 128 GB
Weight & dimensions
Depth: 244 mm
Height: 65 mm
Width: 244 mm
Network
Wi-Fi standards: 802.11a, Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: Yes
Bluetooth version: 4.2
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
LAN controller: Realtek 8111HN
Bluetooth: Yes
Internal I/O
Number of SATA III connectors: 4
RGB LED pin header: Yes
12V power connector: Yes
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Serial port headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of chassis fan connectors: 3
CPU fan connector: Yes
BIOS
Clear CMOS jumper: Yes
Packaging content
Drivers included: Yes
Cables included: SATA
Storage controllers
RAID levels: 1, 0, 10
RAID support: Yes
Supported storage drive interfaces: SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 2.0 ports quantity: 2
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
WiFi-AP antenna jack: 2
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
Other features
Weight: 1 kg
Logistics data
Harmonized System (HS) code: 84733020
Safety warning
Warnings: Dispose of according to local electro-waste regulations., Avoid direct contact with sensitive electronic components., Store away from water and sources of moisture.
