Processor
Supported processor sockets: LGA 1700
Maximum internal memory supported by processor: 128 GB
Processor manufacturer: Intel
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor socket: LGA 1700
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset: Intel B760
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Memory
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 4600, 5200, 3466, 3800, 3333, 5333 MHz, 3400, 3200, 2666, 4266, 3733, 4400, 5000, 2933, 3600, 2133 MHz, 4200, 2400, 5066, 4000, 4800
Maximum internal memory: 128 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
LAN controller: Dragon RTL8125BG
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
Total number of SATA connectors: 4
TPM connector: Yes
S/PDIF out connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
USB 2.0 connectors: 4
Number of SATA III connectors: 4
BIOS
BIOS type: UEFI AMI
Storage controllers
RAID levels: 10, 0, 1, 5
Number of storage drives supported: 6
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, SATA
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
S/PDIF out port: Yes
DisplayPort version: 1.4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
Number of M.2 (M) slots: 2
PCI Express x1 slots: 3
PCI Express x1 (Gen 3.x) slots: 3
PCI Express x16 slots: 2
Safety warning
Warnings: Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply.
