Processor
Compatible processor series: Intel® Pentium® Gold, Intel® Celeron®
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Maximum number of SMP processors: 1
Processor socket: LGA 1700
Features
Power source type: ATX
Windows operating systems supported: Windows 10, Windows 11
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Motherboard chipset: Intel B760
Audio output channels: 7.1 channels
Memory
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory clock speed (max): 6800 MHz
ECC сompatibility: Non-ECC
Supported memory clock speeds: 5600, 4800, 5800, 5400, 6800, 6400, 6200, 5200, 6600, 6000, 5000
Maximum internal memory: 192 GB
Weight & dimensions
Width: 243.8 mm
Depth: 243.8 mm
Network
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b, 802.11ad, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth: Yes
Internal I/O
TPM connector: Yes
ATX Power connector (24-pin): Yes
Front panel connector: Yes
CPU fan connector: Yes
RGB LED pin header: Yes
Front panel audio connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Number of SATA III connectors: 4
USB 2.0 connectors: 4
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Storage controllers
RAID levels: 5, 1, 10, 0
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 2
HDMI version: 2.1
DisplayPort version: 1.4
DisplayPorts quantity: 2
Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
Safety warning
Warnings: Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage.
