Processor
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor socket: LGA 1700
Features
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Motherboard chipset: Intel B760
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Power source type: ATX
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
ECC сompatibility: Non-ECC
Supported memory clock speeds: 6400, 5200, 5000, 6800, 5600, 6600, 6200, 6000, 4800, 5800, 5400
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Weight & dimensions
Depth: 243.8 mm
Width: 243.8 mm
Network
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Internal I/O
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 4
CPU fan connector: Yes
Number of COM connectors: 1
Parallel connector: Yes
TPM connector: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
Chassis intrusion connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging content
Cables included: SATA
Storage controllers
RAID support: Yes
Supported storage drive interfaces: SATA III
Supported storage drive types: HDD & SSD
RAID levels: 1, 10, 0, 5
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
Headphone outputs: 1
HDMI version: 1.4
Line-in: Yes
PS/2 ports quantity: 2
USB 2.0 ports quantity: 4
Microphone in: Yes
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 2
Safety warning
Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
