Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Motherboard chipset: AMD B850
Product colour: White
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Supported memory clock speeds: 8200 MHz, 6400, 6000, 4800, 5600
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200 MHz
ECC сompatibility: Non-ECC
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Wi-Fi: Yes
Internal I/O
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
COM ports quantity: 1
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 connectors: 4
CPU fan connector: Yes
TPM connector: Yes
Number of RGB LED pin headers: 3
Storage controllers
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
RAID support: Yes
RAID levels: 5, 10, 0, 1
Supported storage drive interfaces: M.2, Micro SATA III
Rear panel I/O ports
DisplayPorts quantity: 1
DisplayPort version: 1.2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
USB 2.0 ports quantity: 4
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
