Processor
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Features
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Product colour: Black
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Motherboard form factor: ATX
Windows operating systems supported: Windows 11 x64
Memory
Number of memory slots: 4
Supported memory clock speeds: 4800, 8200 MHz, 5600 MHz, 6000, 6400
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Ethernet LAN: Yes
Bluetooth version: 5.3
Bluetooth: Yes
Wi-Fi standards: 802.11b, Wi-Fi 5 (802.11ac), 802.11n, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O
RGB LED pin header: Yes
CPU fan connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
TPM connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Storage controllers
RAID levels: 0, 1, 10
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
RAID support: Yes
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
DisplayPort version: 1.4
HDMI version: 2.1
Expansion slots
2nd M.2 largest key size: 2280
Number of M.2 (M) slots: 2
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
