Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Motherboard form factor: mini ITX
Component for: PC
Motherboard chipset family: AMD
Product colour: Grey
Memory
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Memory slots type: DIMM
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 8200 MHz
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Ethernet LAN: Yes
LAN controller: Realtek RTL8126
Bluetooth version: 5.4
Wi-Fi standards: 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Bluetooth: Yes
Internal I/O
Number of SATA III connectors: 2
Number of chassis fan connectors: 6
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Chassis intrusion connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
USB 2.0 connectors: 1
CPU fan connector: Yes
TPM connector: Yes
Number of CPU fan connectors: 1
Packaging content
Cables included: SATA
Antenna included: Yes
Screws included: Yes
Storage controllers
RAID support: Yes
RAID levels: 0, 1
Supported storage drive interfaces: M.2, NVMe, SATA III
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C, USB Type-A
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
S/PDIF out port: Yes
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
Other features
Quick installation guide: Yes
