Processor
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Features
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 11 x64
Audio chip: Realtek ALC897
Motherboard chipset family: AMD
Memory
Supported memory clock speeds: 6000, 4800, 6400, 5600 MHz, 8200 MHz
Memory channels: Dual-channel
Maximum internal memory: 256 GB
ECC сompatibility: Non-ECC
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8200 MHz
Weight & dimensions
Width: 243.8 mm
Depth: 243.8 mm
Network
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11g, 802.11ac, 802.11n, 802.11b, 802.11 ax, 802.11a
LAN controller: Realtek RTL8125D
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth version: 5.3
Internal I/O
Front panel connector: Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
Total number of SATA connectors: 4
TPM connector: Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of RGB LED pin headers: 4
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Storage controllers
RAID levels: 10, 0, 1
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPort version: 1.4
Clear CMOS button: Yes
DisplayPorts quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
PCI Express x16 slots: 1
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
PCI Express x1 slots: 2
