Design Fan speed: 500 - 1800 RPM Product colour: Black Fan diameter: 13.5 cm On/off switch: Yes Cooling type: Active Number of fans: 1 fan(s) Illumination: No
Power Number of +12V rail(s): 1 Power Factor Correction (PFC) type: Active Max output current (+3.3V): 22 A Max output current (-12V): 0.3 A Combined power (+12V): 999.6 W Combined power (+3.3V): 120 W Max output current (+5Vsb): 3 A Max output current (+5V): 22 A Max output current (+12V): 83.3 A Combined power (+5Vsb): 15 W Combined power (-12V): 3.6 W Combined power (+5V): 120 W Power protection features: Short circuit, Over voltage, Over power, Overheating, Under voltage, Over current Total power: 1000 W Efficiency: 90% AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz
Weight & dimensions Depth: 150 mm Height: 86 mm Width: 150 mm Weight: 169 g
Performance ATX version: 3.1 Bearing technology: FDB Purpose: PC 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX
Ports & interfaces PCI Express power connectors (16-pin): 1 SATA power cable length: 150, 500 mm PCI Express power connectors (6+2 pin): 4 Peripheral (Molex) power cable length: 500 mm, 450 mm EPS power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX Number of SATA power connectors: 12 Motherboard power cable length: 60 cm Peripheral (Molex) power connectors (4-pin): 1 Cabling type: Fully-Modular EPS power connector (8-pin): No
