Design Illumination: No Product colour: Black Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 13.5 cm
Power Combined power (-12V): 3.6 W AC input frequency: 47 - 63 Hz Efficiency: 90% Total power: 1000 W Combined power (+12V): 999.6 W Power protection features: Overcharge, Surge & inrush protection (SIP), No load operation, Short circuit, Over voltage, Over power, Under voltage, Over total voltage Peak power: 2200 W AC input voltage: 100 - 240 V Combined power (+5V): 100 W Combined power (+5Vsb): 15 W Power Factor Correction (PFC) type: Active Combined power (+3.3V): 100 W Max output current (+3.3V): 20 A
Weight & dimensions Depth: 150 mm Width: 150 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Gold Bearing technology: FDB Power supply unit (PSU) form factor: ATX Purpose: PC
Packaging data Package type: Box
Ports & interfaces ATX Power connector (24-pin): Yes Cabling type: Fully-Modular Number of EPS connectors: 2 Number of SATA power connectors: 11 Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 4 PCI Express connector: Yes Motherboard power connector: 24-pin ATX EPS power connector (8-pin): Yes PCI Express power connectors (16-pin): 1
