Design Product colour: Black Fan speed: 500 - 1800 RPM Cooling type: Active On/off switch: Yes Fan diameter: 12 cm Number of fans: 1 fan(s)
Power AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Power protection features: Short circuit, Over voltage, Over current, Over power Max output current (+5V): 0.3 A Combined power (+5Vsb): 15 W Maximum input current (@220V): 5 A Max output current (+12V): 54 A Efficiency: 85% Maximum input current (@110V): 10 A Combined power (+5V): 120 W Total power: 650 W Max output current (+3.3V): 20 A Power Factor Correction (PFC) type: Active Combined power (+3.3V): 120 W Combined power (+12V): 648 W Max output current (+5Vsb): 15 A
Weight & dimensions Width: 150 mm Depth: 140 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Bronze Power supply unit (PSU) form factor: ATX Purpose: PC
Ports & interfaces ATX Power connector (24-pin): No EPS power connector (4+4 pin): Yes EPS power connector (8-pin): Yes ATX power connector (20+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Motherboard power connector: 20+4 pin ATX Floppy disk drive connector: No Number of SATA power connectors: 3 Motherboard power cable length: 55 cm CPU power connector (4+4 pin): Yes Cabling type: Non-Modular Peripheral (Molex) power connectors (4-pin): 2
