Design Product colour: Black On/off switch: Yes Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 12 cm
Power AC input voltage: 100 - 240 V AC input frequency: 47 - 63 Hz Power Factor Correction (PFC) type: Active Power protection features: Over current, Over power, Short circuit, Over voltage, Overheating Max output current (-12V): 0.3 A Maximum input current (@110V): 8 A Combined power (-12V): 3.6 W Max output current (+3.3V): 20 A Max output current (+5Vsb): 2.5 A Combined power (+12V): 648 W Maximum input current (@220V): 4 A Efficiency: 90% Max output current (+12V): 54 A Combined power (+3.3V): 100 W Max output current (+5V): 20 A Combined power (+5Vsb): 12.5 W Total power: 650 W Combined power (+5V): 100 W
Weight & dimensions Width: 150 mm Depth: 140 mm Height: 86 mm
Performance Power Factor Correction (PFC) type: Active 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: ATX
Packaging data Package type: Box
Ports & interfaces EPS power connector (8-pin): No ATX power connector (20+4 pin): Yes Motherboard power cable length: 60 cm Peripheral (Molex) power connectors (4-pin): 3 Number of SATA power connectors: 6 PCI Express power connectors (6+2 pin): 4 Cabling type: Modular EPS power connector (4+4 pin): Yes ATX Power connector (24-pin): No CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX
